3-10KM Fixed Outdoor FPV Drone Jammer Detection Jamming All In One System Jamming
| Brand Name: | EagleX |
| Model Number: | CC100 |
| Minimum Order Quantity: | 1 |
|
Detail Information |
|||
| Brand Name | EagleX | Model Number | CC100 |
|---|---|---|---|
| Attack Radius: | 1~3 Km (varies By Drone Model; Internal Military Model Differences May Exist) | Attack Frequency Bands: | 2.4 GHz, 5.8 GHz (Other Frequency Can Be Customized) |
| Detection Frequency: | 30 MHz ~ 6 GHz | Detection Radius: | 3-10km (varies By Drone Model; Internal Military Model Differences May Exist) |
| Response Time: | ≤2 S | Detection Coverage: | 360° Full Coverage |
| Positioning Method: | Single Station Drone/target Precise Positioning And Trajectory Tracking | Main Unit Weight: | ≤35 Kg |
| Highlight: | Outdoor FPV Drone Jammer,All In One System Drone Jammer,10KM Fixed Outdoor Drone Jammer |
||
Product Description
FPV Drone Jammer Advanced Drone Detection and Jamming System for Comprehensive Protection
Technical Specifications
| Parameter | Description |
|---|---|
| Detection Range | 30 MHz ~ 6 GHz |
| Key Frequency Bands | 2.4 GHz, 5.2 GHz, 5.8 GHz, 433 MHz, 900 MHz, 1.4 GHz (Other frequency bands configurable) |
| Detection Radius | 3-10 km (varies by drone model; internal military model differences may exist) |
| Response Time | ≤2 s |
| Detection Coverage | 360° full coverage |
| Measurement Accuracy | ≤1° (RMS) |
| Simultaneous Detections | ≥30 targets |
| Positioning Method | Single station drone/target precise positioning and trajectory tracking |
| Positioning Accuracy | ≤3 m (RMS) |
| Wideband Jamming | Supported |
| Jamming Frequency Bands | 2.4 GHz, 5.2 GHz, 5.8 GHz, 1.5 GHz, 0.9 GHz (Other frequency bands configurable) |
| Jamming Radius | 1~3 km (varies by drone model; internal military model differences may exist) |
| Precision Attack | Supported |
| Attack Frequency Bands | 2.4 GHz, 5.8 GHz |
| Attack Radius | 1~3 km (varies by drone model; internal military model differences may exist) |
| Protection Level | IP66 |
| Main Unit Weight | ≤35 kg |
Product Features
-
Passive Detection: The system identifies drone signals and electronic signatures (such as serial numbers) without emitting any electromagnetic signals, allowing for stealth operation.
-
Accurate Positioning: Provides precise geolocation of drones or other aerial targets, including real-time trajectory tracking to ensure comprehensive situational awareness.
-
Target Identification: Distinguishes between different drone models and frequency bands, enhancing the accuracy of countermeasures.
-
Precision Attack: Enables targeted neutralization of specific signals, frequency bands, or individual drones from multiple targets, minimizing collateral interference.
-
Blacklist/Whitelist Function: Offers a one-click option to manage drone access, allowing authorized drones to operate while effectively jamming unauthorized ones.
-
Compatibility: Supports a wide range of drone models, including WiFi drones, hobby drones, fixed-wing UAVs, and DIY drones, ensuring versatility across different operational needs.
-
Applications: Designed for deployment in military installations, public security missions, government facilities, airports, energy infrastructures, high-altitude regions, major public events, and various other critical security contexts.
For more technical support, please contact us now! !
